    섬유로프(Fiber Rope)
    섬유로프 > 3-STRAND
    3-STRAND
    Length : 200m
    SIZE HI MAN PP Mono
    PP Manline
    PP Multi
    Dia
    (mm)
    Dia
    (Inch)
    Circ
    (Inch)
    Weight
    (kg)
    M.B.L(ton) Weight
    (kg)
    M.B.L(ton) Weight
    (kg)
    M.B.L(ton)
    M-Lay MS-Lay M-Lay MS-Lay M-Lay MS-Lay
    3 1/8 3/8       0.85 0.14 1.17 0.85 0.15 0.17
    4 5/32 1/2       1.50 0.22 0.27 1.50 0.24 0.27
    5 3/16 5/8       2.30 0.34 0.42 2.30 0.37 0.42
    6 1/4 3/4 3.50 0.62 0.68 3.50 0.50 0.62 3.50 0.55 0.62
    7 9/32 7/8 4.75 0.84 0.92 4.75 0.67 0.84 4.75 0.72 0.84
    8 5/16 1 6.20 1.10 1.21 6.20 0.85 1.10 6.20 0.92 1.10
    9 3/8 1-1/8 7.80 1.32 1.45 7.80 1.06 1.32 7.80 1.14 1.30
    10 13/32 1-1/4 9.60 1.57 1.73 9.60 1.29 1.57 9.60 1.40 1.57
    11 7/16 1-3/8 11.7 1.90 2.10 11.7 1.54 1.90 11.7 1.70 1.90
    12 15/32 1-1/2 13.9 2.23 2.45 13.9 1.80 2.23 13.9 1.94 2.23
    13 2/1 1-5/8 16.3 2.62 2.87 16.3 2.11 2.62 16.3 2.27 2.62
    14 9/16 1-3/4 18.8 3.05 3.36 18.8 2.40 3.05 18.8 2.60 3.05
    16 5/8 2 24.2 3.77 4.15 24.2 3.00 3.77 24.2 3.24 3.77
    18 23/32 2-1/4 30.8 4.81 5.29 30.8 3.80 4.81 30.8 4.10 4.84
    19 3/4 2-3/8 34.0 5.31 5.84 34.0 4.20 5.30 34.0 4.50 5.30
    20 13/16 2-1/2 38.0 5.80 6.40 38.0 4.50 5.80 38.0 5.00 5.80
    22 7/8 2-3/4 46.0 6.95 7.64 46.0 5.60 6.95 46.0 6.00 6.95
    24 15/16 3 54.7 8.13 8.94 54.7 6.50 8.13 54.7 7.10 8.13
    25 1 3-1/8 59.2 8.8 9.68 59.2 7.00 8.80 59.2 7.70 8.80
    26 1-1/32 3-1/4 63.8 9.40 10.4 63.8 7.50 9.40 63.8 8.20 9.40
    28 1-1/8 3-1/2 73.6 10.7 11.8 73.6 8.50 10.7 73.6 9.30 10.7
    30 1-3/16 3-34 85.2 12.2 13.4 85.2 9.90 12.2 85.2 11.0 12.2
    32 1-1/4 4 96.7 13.5 14.9 96.7 11.0 13.5 96.7 12.1 13.5
    34 1-11/32 4-1/4 110.0 15.4 16.9 110.0 12.4 15.4 110.0 13.6 15.4
    36 1-7/16 4-1/2 122.0 16.9 18.6 122.0 13.7 16.9 122.0 15.1 16.9
    38 1-1/2 4-3/4 135.0 18.7 20.6 135.0 15.1 18.7 135.0 16.6 18.7
    40 1-19/32 5 152.0 20.5 22.5 152.0 16.7 20.5 152.0 18.4 20.5
    42 1-21/32 5-1/4 167.0 22.5 24.8 167.0 18.5 22.5 167.0 19.9 22.2
    45 1-25/32 5-5/8 191.0 25.0 27.6 191.0 20.7 25.0 191.0 22.8 25.0
    48 1-7/8 6 218.0 28.6 31.5 218.0 23.6 28.6 218.0 26.3 28.6
    50 2 6-1/4 236.0 31.0 34.1 236.0 25.5 31.0 236.0 28.6 31.0
    55 2-5/32 6-7/8 286.0 36.5 40.2 286.0 30.0 36.5 286.0 33.6 36.5
    56 2-1/4 7 296.0 37.8 41.6 296.0 31.0 37.8 296.0 34.8 37.8
    60 2-3/8 7-1/2 340.0 43.3 47.6 340.0 35.5 43.3 340.0 40.0 43.3
    64 2-1/2 8 387.0 49.0 53.9 387.0 40.0 49.0 387.0 44.8 49.0
    65 2-9/16 8-1/8 399.0 50.5 55.6 399.0 41.0 50.5 399.0 46.1 50.5
    72 2-7/8 9 490.0 61.5 67.7 490.0 50.3 61.5 490.0 56.0 61.5
    80 3-5/32 10 605.0 75.6 83.2 605.0 60.5 75.6 605.0 68.4 75.6
    85 3-11/32 10-1/2 683.0 85.3 93.8 683.0 68.0 85.3 683.0 76.8 85.3
    90 3-9/16 11-1/8 765.0 95.5 105.0 765.0 75.0 95.5 765.0 84.7 95.5
    96 3-25/32 12 871.0 107.0 118.0 871.0 84.7 107.0 874.0 95.8 107.0
    100 3-15/16 12-3/8 945.0 116.0 128.0 945.0 91.5 116.0 945.0 104.3 116.3
    Length : 200m
    SIZE Polythylene Nylon Polyster
    (Mult. Type)
    Vinylon Manila
    &
    Sisal
    Dia
    (mm)
    Dia
    (Inch)
    Circ
    (Inch)
    Weight
    (kg)
    M.B.L(ton) Weight
    (kg)
    M.B.L(ton) Weight
    (kg)
    M.B.L(ton) Weight
    (kg)
    M.B.L(ton) Weight
    (kg)
    M.B.L(ton)
    3 1/8 3/8 0.90 0.11 1.14 0.21     1.20 0.09
    4 5/32 1/2 1.60 0.20 1.94 0.33 2.36 0.30 2.00 0.15 2.20 0.12
    5 3/16 5/8 2.50 0.30 3.00 0.55 3.86 0.40 3.10 0.23 3.40 0.18
    6 1/4 3/4 3.60 0.42 4.43 0.75 5.40 0.56 4.50 0.33 5.00 0.26
    7 9/32 7/8 5.00 0.55 6.00 1.02 7.50 0.77 6.10 0.43 7.00 0.36
    8 5/16 1 6.40 0.70 7.76 1.35 9.60 1.02 7.90 0.56 9.50 0.48
    9 3/8 1-1/8 8.00 0.88 9.80 1.72 124. 1.27 10.0 0.70 12.0 0.61
    10 13/32 1-1/4 10.0 1.10 12.1 208 15.2 1.59 12.4 0.95 14.0 0.63
    11 7/16 1-3/8 12.4 1.36 14.6 2.54 18.6 1.93 15.1 1.16 17.0 0.77
    12 15/32 1-1/2 15.0 1.54 17.6 3.00 22.0 2.27 17.8 1.37 21.0 0.95
    13 2/1 1-5/8 17.0 1.74 20.6 3.50 25.8 2.66 21.0 1.62 24.1 1.09
    14 9/16 1-3/4 19.0 2.09 23.9 4.10 29.6 3.18 24.2 1.83 28.0 1.28
    16 5/8 2 25.0 2.80 31.0 5.30 39.0 4.10 31.5 2.34 38.0 1.80
    18 23/32 2-1/4 32.0 3.47 38.9 6.70 49.0 5.10 39.8 2.92 44.0 2.14
    19 3/4 2-3/8 36.0 3.90 43.4 7.50 54.8 5.70 44.4 3.26 50.0 2.43
    20 13/16 2-1/2

    40.0

    4.27 48.0 8.30 60.6 6.40 49.0 3.55 55.0 2.85
    22 7/8 2-3/4 48.0 5.08 57.9 10.0 73.4 7.77 59.2 4.24 66.0 3.41
    24 15/16 3 57.0 6.10 69.5 12.0 87.4 9.20 70.4 4.98 80.0 4.07
    25 1 3-1/8 62.0 6.60 75.0 12.9 94.7 10.0 76.4 5.40 87.0 4.43
    26 1-1/32 3-1/4 67.0 6.93 81.3 14.0 102.0 10.7 82.5 5.78 94.0 4.73
    28 1-1/8 3-1/2 78.0 8.21 94.6 15.8 118.0 12.3 95.6 6.64 106.0 5.32
    30 1-3/16 3-34 90.0 9.48 108.0 17.8 136.0 13.7 109.0 7.55 125.0 6.10
    32 1-1/4 4 102.0 10.7 123.0 20.0 155.0 15.7 124.0 8.51 140.0 6.86
    34 1-11/32 4-1/4 115.0 12.0 139.0 22.6 176.0 17.5 140.0 9.53 159.0 7.79
    36 1-7/16 4-1/2 129.0 13.4 155.0 24.9 196.0 19.4 157.0 10.6 178.0 8.70
    38 1-1/2 4-3/4 144.0 15.0 174.0 27.4 220.0 21.6 175.0 11.7 199.0 9.72
    40 1-19/32 5 159.0 16.3 191.0 30.0 243.0 24.0 194.0 12.9 220.0 10.5
    42 1-21/32 5-1/4 176.0 18.0 213.0 33.0 268.0 26.1 213.0 14.1 243.0 11.6
    45 1-25/32 5-5/8 203.0 20.8 244.0 37.0 308.0 29.8 245.0 16.0 278.0 13.2
    48 1-7/8 6 229.0 22.8 277.0 42.0 350.0 33.6 279.0 17.9 317.0 14.8
    50 2 6-1/4 249.0 24.7 302.0 45.5 380.0 36.3 302.0 19.5 345.0 16.1
    55 2-5/32 6-7/8 300.0 29.6 367.0 54.2 459.0 42.8 355.0 23.3 417.0 19.4
    56 2-1/4 7 312.0 30.4 380.0 56.0 476.0 44.8 370.0 24.3 432.0 19.9
    60 2-3/8 7-1/2 360.0 34.4 438.0 63.8 546.0 49.9 433.0 27.4 496.0 22.6
    64 2-1/2 8 412.0 39.1 496.0 72.0 622.0 58.0 493.0 30.9 564.0 25.7
    65 2-9/16 8-1/8 425.0 4.02 513.0 74.2 642.0 59.0 508.0 31.8 581.0 26.4
    72 2-7/8 9 521.0 49.1 630.0 90.0 786.0 72.1 623.0 38.6 713.0 32.7
    80 3-5/32 10 646.0 60.4 777.0 110.0 970.0 88.5 767.0 46.8 880.0 38.8
    85 3-11/32 10-1/2 729.0 68.1 874.0 124.0 1090 98.8 866.0 52.4 993.0 43.8
    90 3-9/16 11-1/8 818.0 76.4 980.0 137.0 1220 110.0 973.0 58.2 1113 49.1
    96 3-25/32 12 930.0 85.4 11110 154.0 1400 126.0 1100 65.6 1260 53.5
    100 3-15/16 12-3/8 1009.0 92.6 1200 166.0 1500 136.0 1200 70.8 1370 58.2
